Drawing from more than three decades of experience in the oil and gas industry, we set out to solve challenging problem in the field. Our research and development for HPU (Hydraulic Pumping Unit) and other oil & gas services has been proven by breaking into local oil and gas market with over 200 products running in the field.


About Us

We are an engineering company, like engineers, we solve problem. With problem solving mindset, we always try to innovate and create simpler and elegant solution to problem. Our mission is to take product that is “made in Indonesia” locally and globally.

We have achived certification for ISO 9001, ISO 14001 and OHSAS 18001. Audited by LLOYD'S REGISTER (LRQA)

Our Team

Our History

EXP started as a small workshop in Cikunir, Indonesia. Drawing from more than three decades of experience in the oil and gas industry, we set out to solve challenging problem in the field. Our research and development for HPU and other oil & gas services has been proven by breaking into local oil and gas market with over 200 products running in the field. We are known for our reliable product and swiftness in tackling problems. We are passionate to manufacture product which has quality of not only the best in its class locally, but globally. We are in pursuit of simple and elegant solutions to problem which are reflected in the simplicity in design and operation of our products.

HPU Hydraulic Pumping Unit

With over 200+ of products running on the field, we are currently the market leader for HPU in Indonesia. Our product has been proven for more than 7 years in the field, you can rest assured that you are dealing with a reputable company that is best in its class

Our Products

We put reliability as our top priority for products. Our products are simple to install and operate, ready to solve complicated problems of the oil and gas industry

HYDRAULIC PUMPING UNIT

Artificial lift solution that is simpler and more reliable then pump jack.

JET PUMP & WATER INJECTION

Alternative lift solution for “dirty” oil well

LINEAR KINETIC CELL

Parrafin control system to smooth your clogged or turbulent pipe flow

STRONGBACK

To protect gas or oil distribution pipe without the need to turn off flow, very quick cure time and high heat resistance.

PUMP SHOP

We have the complete facilities to fix your tubing pump

GENERATOR

If you have natural gas and need electricity, these generators will convert it for you

COMPRESSOR

Custom made gas compressor

HYDRAULIC PUMPING UNIT



Hydraulic Pumping Unit

  • 120” Stroke Length Capacity
  • Maximum 8 SPM (Stroke per Minute)
  • 16.000 lbs. Rod Lift System
  • Direct Wellhead Mount System
  • Mast tower of 4 column telescopic direct mounted to Wellhead 7-1 / 16 with rating 2000, 3000, 5000
  • Ground Level Stroke Length Adjustment
  • Down Stroke Bypass Assembly
  • Safety devices to protect the system against rod stuck on either down or up stroke
  • No guideline required

Hydraulic Component

  • Single Actin Hydraulic Cylinder
  • Variable Displacement Pump
  • Directional Control Valve
  • Bladder Type Accumulator (2 x 50L)
  • Hydraulic Cooler
  • Hydraulic Filter
  • Relief Valve
  • Environment Friendly hoses and fittings
  • Low level shut down System
  • High-temp shut down System
  • Hydraulic flow control System


Electric Motor Power pack

Electric motor with specification:
  • Power Rating: 24.2 HP 460/60 Hz Class 1 Division 2 Zone 2
  • Control Panel


Gas Engine Power Pack

Natural Gas Engine with the following specification:
  • Overhead valve cylinder with replaceable guide and seat
  • Natural Gas Carburetors with Mechanical Governor (no electronic governors)
  • Capacitor Discharge Ignition (CDI) System with individual coil for each cylinder
  • Heavy Duty Flywheel
  • Full Instrument Panel with tachometer, hour meter, oil pressure, water temperature, oil level
  • Power rating: 51.9 HP
  • Environment friendly skid unit complete with hydraulic tank

Other Product...

JET PUMP & WATER INJECTION



Water Injection Pump

  • Max. Pressure = 1200 psi
  • Max. Capacity = 1200 BWPD (BBL water per day)
  • Operation Temp. Max. = 160 Deg. F / 71 Deg. C
  • Diaphragm Pump Driven by Electric Motor 30 HP on Galvanized Steel Skid & Canopy, include:
  • Suction Line: Low Pressure Switch, Pressure Gauges, Strainer, Valve
  • Discharge Line: High Temperature Switch, Digital Flowmeter Pressure
  • Safety Valve, Check Valve, Bypass Line/Flow Regulator


Hydraulic Jet Pump

DOWNHOLE EQUIPMENT

  1. Equipment Attached to 3-1/2” Tubing :
    1. 2.31” Seating Nipple
    2. X-Over 3-1/2” EUE x 2-7/8” EUE
  2. 1.66” OD Inner Tubing (1.38” ID) Integral Joint, J-55 NU
    1. 10rd Connection
  3. Equipment Attached to 1.66 I.J. Tubing:
    1. Brass Strainer Nipple
    2. Hold Down Seal Assembly
    3. 2” Jet Pump Housing c/w Top and Bottom Sub
    4. Pump Assy consist of:
      1. Carrier
      2. Mixing Tube & Nozzle
  4. Surface Equipment Flow Head Assembly
    1. Stuffing Box
    2. Valve for flowing manipulation
  5. Surface Pumping Unit:
    1. D-35 Ultra Flo Diaphragm Pump 30 HP electric motor with max. Cap 1200 bpd
    2. Flow Meter
    3. PSV
    4. Bypass Valve
    5. Hi-Lo Shut Down System

Other Product...

LKC (LINEAR KINETIC CELL)


  • For 2”, 3”, 4” pipeline
  • Paraffin/Scale Control System
  • Liquid output flow in Laminar Flow Pattern
  • Requires no Chemicals
  • No Pollution
  • Easy Installation

Other Product...

STRONGBACK


  • Application method: Water activated wet layup
    • Cure time is 30-60 minutes
    • Heat resistance (after 24 hour cure) up to 260 deg. Celsius
    • Max Installation temperature 126 deg. Celsius
    • Nonconductive when cured (16,000 Volts)
  • Applications:
    • Pipe Reinforcement and Rehabilitation
    • Abrasion Protection
    • Corrosion Protection
    • Pipe Leak
    • Repair Encapsulation
    • Structural Repair
    • Dielectric Protection
    • Duct Sealing

Other Product...

PUMP SHOP

Our Service includes:

Tubing Pump Repair

We have the complete facilities to fix your tubing pump. No more waiting a long time to fix tubing pump overseas, all of your repair needs are available with us.

Before
After

   Some of our facilities include:

Centerless Grinder
Metal Spray
Fusing
Straightening


Other Product...

GENERATOR



NATURAL GAS ENGINE GENSET 36 KVA (OPEN TYPE SKID)

  • Engine Spec: 6 Cylinder Natural Gas Engine Arrow, includes: Gas
  • Regulator & Mini Scrubber
  • Genset spec: +/- 36 KVA, 3 Phase, @ 50 Hz

Other Product...

COMPRESSOR


  • Custom Made gas Compressor
  • Contact us for more information

Other Product...

FAQ

This is a short list of our most frequently asked questions. For more information about Exp, or if you need support, please visit contact us.

FAQ

EXP started as a small workshop in Cikunir, Indonesia. Drawing from more than three decades of experience in the oil and gas industry, we set out to solve challenging problem in the field. Our research and development for HPU and other oil & gas services has been proven by breaking into local oil and gas market with over 200 products running in the field. We are known for our reliable product and swiftness in tackling problems. We are passionate to manufacture product which has quality of not only the best in its class locally, but globally. We are in pursuit of simple and elegant solutions to problem which are reflected in the simplicity in design and operation of our products.
Our products and services are Hydraulic Pumping Unit (HPU), Jet Pump & Water Injection, Linear Kinetic Cell, Strongback, Pump Shop, Generator & Compressor

Why HPU

Content on this page requires a newer version of Adobe Flash Player.

Get Adobe Flash player

   HPU

Installation

  • No need for foundation
  • Ready to operate in + / - 2 hours
  • Easy to mobilize (small footprint)

Unit Operation

  • Easy and quick to set SPM using knob
  • Easy and quick to set Stroke Length by changing limit switch position
  • Quick and easy for rig up or rig down to minimize production downtime
  • Can set different speed for up motion and down motion
  • Can be moved up or down in steps or stop for well optimization using dynagraph

   PUMP JACK

Installation

  • Need foundation
  • May take a week
  • Large footprint, hard to mobilize

Unit Operation

  • Complicated and time consuming to change SPM
  • Complicated and time consuming to change Stroke Length and need tools with experienced personnel
  • Slow and complicated rig up and rig down process, extending production downtime
  • Same up and down motion speed
  • Not practical for dynagraph optimization

Disclaimer
Illustration is based on assumption that everything runs smoothly in ideal condition. Assumption also made at week 3 where pump jack needs maintenance or having downtime. The rate of pumping for both pumps are made equal with downhole equipment are also in equal rate. Exp does not claim in any way that customer will definitely gets production rate as illustrated.

Our Clients

With over 200+ of products running on the field, we are currently the market leader for HPU in Indonesia. Out clients range from big oil company such as Pertamina, Total and Medco, to smaller ones such as Formasi Sumatera Energi. We are currently on process to break into the Global Market with interest from Malaysia to as far as Libya. Our round of customer survey has given us 90.245% rating in customer satisfaction which says a lot of our product reliability, on time delivery and after sales service. As our product has been proven for more than 7 years in the field, you can rest assured that you are dealing with a reputable company that is best in its class.

Survey Facts

Our round of customer survey has given us 90.245% rating in customer satisfaction which says a lot of our product reliability, on time delivery and after sales service.

Career with Us

We are an engineering company, like engineers, we solve problem. With problem solving mindset, we always try to innovate and create simpler and elegant solution to problem. Our culture is to let people make mistakes, as long as they learn from then, but we won’t tolerate deliberate mistake and repetitive mistake without progress towards solution. Our mission is to take product that is “made in Indonesia” locally and globally. We are ready to change the world, and we need brilliant, creative, innovative, helpful people to help us in our mission.

Are you one of them? send your CV to expertest@cbn.net.id

Get In Touch

One way to get in touch with us is to fill out the following form. Please provide as much information as you can, one of us will be in touch with you soon !

Contact Info

PT. Expertest Kaliper Nusantara
Office & Workshop :
Jl. Cikunir Raya No.8 Cikunir - Bekasi
+62 811 8403 031
expertest@cbn.net.id
Cordinate: -6.28705, 106.95991
